| Place of Origin | CHINA |
| Brand Name | BEITE |
| Certification | CE ISO |
Description
An ultrasonic flowmeter specially designed for small pipe measurement, which solves the problems of ordinary clamp-on flowmeters being unsuitable for installation and unstable measurement on small pipe diameters. It can be installed in complex locations in pipelines, takes up little space, and can measure locations that ordinary flowmeters cannot measure;
Advantage:
It can be installed in complex locations in pipelines, takes up little space, and can measure locations that ordinary flowmeters cannot measure;
The integrated one supports a minimum pipe diameter of DN15 (20) and a maximum pipe diameter of DN80 (90);
Supports stainless steel pipes, carbon steel pipes, copper pipes, plastic pipes and other material pipes;
Application scenarios:
Small diameter liquid measurement in cleaning machines, irrigation, beverage and food feeding, solar panel cleaning, database, etc.
specification
| Product number | X3 split |
| Flow range | 0.1m/s~5.0m/s |
| Accuracy | ±2.0% |
| Repeatability | 0.8% |
| Measure pipe diameter | 9.53 to 90 |
| Storage function | With daily, monthly and annual flow accumulation |
| Analog output | 4~20mA, maximum load 600Q |
| Alarm Output | OCT upper and lower limit alarm function (optional) |
| Communication Interface | RS485, supports Modbus communication protocol |
| power supply | 24VDC |
| cable length | 2.0 meters |
| keyboard | Four touch buttons |
| show | OLED 128*64 dot matrix display |
| unit | Supports metric and imperial unit selection, Cubic Meters (m³), Liters (L), USA Gallons (GAL), You can press /hour (per hour), /min (per minute), the factory default unit is m³/h |
| totalizer | 6-digit flow totalizer |
| Suitable for pipes | Stainless steel, carbon steel, copper pipe, plastic pipe |
| shell material | Aluminum alloy |
| ambient temperature | 0℃~50℃(32°F~122°F) |
| Medium temperature | 0℃~50℃(32°F~122°F); optional high temperature sensor: 0℃~110℃(32F~230°F) |
| environment humidity | Relative humidity 0~95%, no condensation |
| Protection level | IP54 |
Packing & Delivery
FAQ
1. Q: What information need to be provided to choose the suitable model?
A: Application field, Nominal pressure ,Medium & medium temperture , Power supply , Output,
Flow range, Accuracy, Connection and other parameters.
2. Q: Are you a trade company or a manufacturer?
A: We are an ISO approved manufacturer specialized in level and flow measuring instruments.
OEM & ODM service are available. Welcome to visit us in China.
3. Q: What is your MOQ?
A: To start our cooperation, sample order is acceptable.
4. Q: What is your delivery date for the Intelligent Mini Micro Turbine Fuel Oil Diesel Flow Meter?
A: The delivery date is about 3-15 working days after receipt of payment.
5. Q: What is your payment terms?
A: We support T/T, PayPal ,Western Union.
For mass production order, it is 30% deposit in advance and 70% balance before shipment.
6. Q: Do you have a warranty for the Flow Meter?
A: Yes, we have the warranty of 12 months.
