| Place of Origin | CHINA |
| Brand Name | BEITE |
| Certification | CE ISO |
Description
Note:
1. Fluid: water
2. Working pressure: <0.6MPa
3. Test pressure: 1.0MPax30min
4. Operating temperature: below 120°C
5. Pressure loss: <70kPa
6. Accuracy level: ±5%
7. Mark the direction of water flow at the appropriate location
8. Flange standard: HG20592 PN16 RF
| DN | A | B | Model specifications | flow(m³/h) | |
| 〔00 | DN80 | 400 | 210 | LF-[-80 | Q~8Q |
| 〔01 | DN80 | 400 | 210 | LF-(-80 | 0~8Q |
| 〔02 | DN100 | 400 | 220 | LF-C-100 | 0~100 |
| DN100 | 400 | 220 | LF-〔-100 | 0~100 | |
| DN125 | 500 | 260 | LF-〔-125 | 0~150 | |
| 〔05 | DN125 | 500 | 260 | LF-C-125 | 0~150 |
| 〔06 | DN150 | 500 | 270 | LF-C-150 | 0~200 |
| 〔07 | DN150 | 500 | 270 | LF-C-150 | Q~20Q |
| 〔08 | DN200 | 600 | 300 | LF-〔-200 | 0~350 |
| 〔09 | DN200 | 600 | 300 | LF-[-20 | 0~35Q |
Packing & Delivery
FAQ
1. Q: What information need to be provided to choose the suitable model?
A: Application field, Nominal pressure ,Medium & medium temperture , Power supply , Output,
Flow range, Accuracy, Connection and other parameters.
2. Q: Are you a trade company or a manufacturer?
A: We are an ISO approved manufacturer specialized in level and flow measuring instruments.
OEM & ODM service are available. Welcome to visit us in China.
3. Q: What is your MOQ?
A: To start our cooperation, sample order is acceptable.
4. Q: What is your delivery date for the Intelligent Mini Micro Turbine Fuel Oil Diesel Flow Meter?
A: The delivery date is about 3-15 working days after receipt of payment.
5. Q: What is your payment terms?
A: We support T/T, PayPal ,Western Union.
For mass production order, it is 30% deposit in advance and 70% balance before shipment.
6. Q: Do you have a warranty for the Flow Meter?
A: Yes, we have the warranty of 12 months.
